Description
1111 mm (44″), 102 mm (4″), 297 mm (12″)
9,7 kg (21lb)
GENERAL
• Master Level Control
• Wooden Pitch Stick
• Modulation Wheel
• 21 x 6 Program Locations
• 2 Live Buffers
• 2 Individual Panel Setups
• 3 Morph sources (Modulation Wheel, Control Pedal, Aftertouch)
ORGAN SECTION
• B3 Tone Wheel Organ, Vox Continental and Farfisa models with full polyphony
• 9 Digitally Controlled Drawbars
• Percussion Controls
• Vibrato / Chorus Control
• 2-Part Multitimbral (2 manuals)
PIANO SECTION
• Acoustic Grand Pianos
• Upright Pianos
• Electric Pianos
• Wurlitzer A200 Electric Piano
• Clavinet D6
• Harpsichord
• CP-80 Electric Grand
• 40-60 Voices Polyphony
• 4 Selectable Velocity Curves
• Clavinet EQ Controls
• 2-Part Multitimbral SYNTH SECTION
• Analog synthesis : 10 Modeling Waveforms including Dual Saw, Hard Sync and PWM
• FM synthesis: 2 & 3 Operator FM Synthesis
• Wavetables synthesis: 77 waveforms
• 16 Voices Polyphony
• Unison Control with no reduction in polyphony
• Timbre Controls
• Amplitude Envelope
• Modulation Envelope
• 12/24 dB LowPass Filter with Resonance
• 300 Memory Locations, 3 Categories
• 2-Band Equalizer
• 2-Part Multitimbral COMMON PARAMETERS
• Level Control
• Zone (split assignment) Control
INSTRUMENT EFFECTS
• Unit 1: Ring Modulator, Tremolo, Pan, Wah 1, Wah 2, AutoWah
• Unit 2: 2 Flangers, 2 Phasers, 2 Choruses Delay includes Ping Pong and TapTempo Function
• Amplifier/Speaker Simulation: 3 types of Speaker simulations, 3-band Equalizer and Overdrive
• Rotary Speaker: selectable Speed and Overdrive MASTER EFFECTS
• Compressor
• Reverb – 5 Algorithms KEYBOARD
• 88/76-models: Hammer Action Weighted Keys
• Compact-model: Medium Weighted Keys
• Aftertouch
• Supports 3 split zones with visual LED indication
CONNECTIONS
• 4 Assignable Audio Outputs ¼ », 6,35 mm jacks, unbalanced
• Stereo Headphone Output – ¼ », 6,35 mm stereo jack
• Sustain Pedal ¼ », 6,35 mm jack.
• Rotor Pedal ¼ », 6,35 mm jack. Use a momentary pedal or a switch type pedal
• Organ Swell Pedal ¼ », 6,35 mm TRS stereo jack. Use a Control/Expression pedal like e.g. Yamaha FC-7, Roland EV-5 etc.
• Control Pedal ¼ », 6,35 mm TRS stereo jack.
• MIDI In 5 pin DIN connectors
• MIDI Out 5 pin DIN connectors
• USB – type B connector
• IEC320 C7 power connector
